Wire mesh belt conveyor shot blasting machine

If the machine is not suitable for your workpiece, please tell us the following infromation:

What kind of workpiece will you clean?

What is the maximum size of the workpiece? (length, width and height)

What is the maximum weight of the workpiece?

What is the cleaning efficiency required?

According to your infomation, the most suitable machines will be designed for your workpieces.

Get a quote

Click Here to View a working video of the ANTAI Wire mesh belt conveyor shot blasting machine



Wire mesh belt shot blasting machine is suitable for continuous blasting thin and collision-sensitive die castings, pressure castings, ferrous and non-ferrous castings, forgings, automotive accessories, and weldments. Workpiece weight ranging from 1kg to 100kg. A highly wear-resistant wire mesh belt, with tension adjustment, provides the part transport. Wire mesh belt width has 600mm, 800mm, 1000mm and 1200mm. Due to the wire mesh belt, the workpieces can be blasted both from upper and bottom. Normally the machine has 4 blast wheel, 6 blast wheels or 8 blast wheels.

Application range

Wire mesh belt shot blasting machine is a new type of special equipment designed and manufactured according to user requirements. It is mainly used for surface shot blasting of thin-walled castings, thin-walled and fragile iron or aluminum alloy castings, ceramics and other small parts. It can also be used for shot peening of mechanical parts. Has good continuity. It has the advantages of high cleaning efficiency, small deformation and no pits; it can be used alone or in wiring. It can apply strong shot blasting to the original steel and casting surface, remove the rust layer, welding slag and scale, to obtain uniform metallic luster, eliminate the surface stress of the workpiece, and improve the finishing of the steel. Quality and anti-corrosion effect.

wire mesh.jpg

Technical characteristics



网带 拼图.jpg
